Sensitronics' single element ShuntMode FSR (1-inch diameter) provides precise single-zone force measurement.
This versatile sensor is used in a wide range of designs, including human interface devices, robotics, and automotive sensing applications.
Lead time: ~1 Month
Need larger quantities or custom specifications? Contact us for volume pricing.
| Property | Value | Notes |
|---|---|---|
| Size Range | 1" Diameter. | See line diagram for overall dimensions. |
| Tail Length with Connector | 0.8" or 1.3" (if important, please email before ordering) | |
| Force Sensitivity Range | 1 lbs. to 100 lbs. | With force spread across active area. |
| Pressure Sensitivity Range | 1 psi to 125 psi | Mechanical Interface dependent |
| Part-to-Part Force Repeatability | approx. +/- 15% of average resistance | With consistent actuation |
| Maximum Current | .5 mA | |
| Single Part Force Repeatability | +/- 5% of established nominal resistance | With consistent actuation |
| Force Resolution | 1% full scale | |
| Stand-Off Resistance | 10M ohm or greater | |
| Switch Travel | .005" | |
| Device rise time | 15 kHz or faster | |
| Lifecycle | 1 million plus actuations | |
| Temperature Range | -15°F to + 200° F | |
| Device Thickness | .017" | |
| Pliability |
