Technical Documents
Sensor Characteristics
| Property | Value | Notes |
| Size Range | 22" x 34" Maximum Size | Any shape - compound curves |
| Force Sensitivity Range | 0 oz. to 100 lbs. | Mechanical interface dependent |
| Pressure Sensitivity Range | 0 psi to 1000 psi | Mechanical Interface dependent |
| Part-to-Part Force Repeatability | approx. +/- 20% of average resistance | With consistent actuation |
| Maximum Current | .5 mA | |
| Single Part Force Repeatability | +/- 5% of established nominal resistance | With consistent actuation |
| Force Resolution | 1% full scale | |
| Stand-Off Resistance | 100K Ohms to 1M Ohms | No load - formula dependent |
| Switch Travel | zero to thickness of spacer | |
| Device rise time | ~20usec / 50kHz | |
| Lifecycle | 1 million plus actuations | |
| Temperature Range | -15°F to + 200° F | Substrate specification limitations |
| Device Thickness | Substrate and spacer dependent | |
| Pliability |
